According to the latest statements by the World Health Organization, the problem with coronavirus will not be resolved in the very near future, and on the recommendation of the EU, measures that are currently being taken must be released - this means that there will be a risk of infestation - such as now. To do this, it is necessary to take very serious measures to control people-to-people contacts.
The startup company Media Prime, along with a manufacturer in Hong Kong, offers an affordable access control system base on low-cost high-tech device with thermal imaging module for determining a person’s temperature and a face with mask live recognition system that can control access to public places for people with body temperature in a given range.
There are 3 possible uses:
1. Standalone - The device is used without additional software.
2. Local Area Mode - We will provide access control software.
3. Cloud Mode - The software described above will be installed on a cloud system.
Use the demo installation here to test the software.
user: admin pass: 123456
Parameters for the module
|
Camera |
Resolution |
2 million pixels |
|
Type |
Binocular wide dynamic camera |
|
|
Aperture |
F2.4 |
|
|
Focusing distance |
50-150cm |
|
|
White balance |
auto |
|
|
Photo flood light |
LED and IR dual photo flood light |
|
|
Screen |
Size |
8.0 inch IPS LCD screen |
|
Resolution |
800x1280 |
|
|
Touch |
Not supported (optional support) |
|
|
Processor |
CPU |
RK3288 quad-core (optional RK3399 six-core, MSM8953 eight-core) |
|
Storage |
EMMC8G |
|
|
Interface |
Network module |
Ethernet and wireless (WIFI) |
|
Audio |
2.5W / 4R speakers |
|
|
USB |
1 USB OTG, 1 USB HOST standard A port |
|
|
Serial communication |
1 RS232 serial port |
|
|
Relay output |
1 door open signal output |
|
|
Wiegand |
One Wiegand 26/34 output, one Wiegand 26/34 input |
|
|
Upgrade button |
Support Uboot upgrade button |
|
|
Wired network |
1 RJ45 Ethernet socket |
|
Function |
Credit card reader |
None (optional IC card reader, ID card, ID card) |
|
Face Detection |
Supports detection and tracking of multiple people at the same time |
|
|
Face library |
Up to 30,000 |
|
|
1: N face recognition |
Support |
|
|
1: 1 face comparison |
Support |
|
|
Stranger detection |
Support |
|
|
Identify distance configuration |
Support |
|
|
UI interface configuration |
Support |
|
|
Upgrade remotely |
Support |
|
|
Interface |
Interfaces include device management, personnel / photo management, record query, etc. |
|
|
Deployment method |
Support public cloud deployment, privatized deployment, LAN use, stand-alone use |
|
|
Infrared thermal imaging module |
Temperature detection |
Support |
|
Temperature detection distance |
1 meter (optimal distance 0.5 meter) |
|
|
Temperature measurement accuracy |
^ ±0.30 |
|
|
Temperature measurement range |
100-420 |
|
|
Thermal field of view |
32 X 320 |
|
|
Visitors' temperature is normal and released directly |
Support |
|
|
Abnormal temperature alarm |
Support (temperature alarm value can be set) |
|
|
General parameters |
Power |
DC12V(±10%) |
|
Operating temperature |
00-600 |
|
General parameters |
Storage temperature |
-200-600 |
|
Power consumption |
13.5W(Max) |
|
|
Installation method |
Gate bracket installation |
|
|
Size |
Standard:274.24*128*21.48 (mm) |
|
|
IC card / ID card:296.18*132.88*25 (mm) |
||
|
|
Business plan:
Within 2 weeks, we expect to get the EU brand as a new product in the EU market. This project is very important for the image of the company, so that we can bring the product to the market as quickly as possible. We trained specialists for the installation of equipment and systems. We can remotely train EU specialists on how to install equipment. We can install the software remotely.
